Hioki Single & Three-Phase Handheld Clamp On Power Hi-Tester, 3286-20
Price inclusive of VAT
Qty Per Pack : 1 Piece
Min Orderable Qty : 1 Pack
Key features
- Its Clamp On Power Meter Can Measure Voltage, Current, Power, Power Factor, Phase Angle, Reactive Power or Frequency, As Well As Detect Phase Sequence On Live Lines at Any Desired Point of a Single-Phase Circuit or Three-Phase Circuit.
Product Specifications
Brand | Hioki |
Rated Power Range | at (80 - 600 V & 1 - 1000 A) : [Single phase] 3.000 kW to 600.0 kW, Basic accuracy: ±2.3 % rdg. ±5 dgt. (at 50/60 Hz, Power factor = 1) [Balanced three phase] 6.000 kW to 1200 kW, Basic accuracy: ±3.0 % rdg. ±10 dgt. (at 50/60 Hz, Power factor = 1) |
Measurement Current Range | at (45 - 1kHz) : 20.00 A to 1000 A, 3 ranges, Basic accuracy: ±1.3 % rdg. ±3 dgt. (at 45 - 66 Hz, True RMS) |
Counts | Max. 6000 digits |
Display Refresh Rates | 1 time/s (Normal) 1 time/3s (Slow), 1 time/2s (Harmonic level) |
Measurement System | Single-phase, Three-phase (balanced with no distortion) |
Model No | CM3286 |
Battery Type | Stacked alkaline battery (6LR61, 6LF22) |
Voltage Range | at (30 - 1kHz) : 150.0 V to 600 V 3 ranges Basic accuracy: ±1.0 % rdg. ±3 dgt. (at 45 - 66 Hz, True RMS) |
AC Current Range | 0.060 A to 600.0 A |
Battery Backup | 25 hrs (Backlight OFF) |
Type of Product | Hi-Tester |
Protection | Dustproof & Waterproof: IP54 (EN60529) Grip |
Interface | Bluetooth 4.0LE, display measured values on an iOS or Android device |
Core Jaw Diameter | 55 mm or 80x20 mm bus-bar |
Display | LCD |
